Blue Sea 25A A-Series COTS Circuit Breaker

SKU# BS7314
$11799
Check Delivery Time

Blue Sea 25A A-Series COTS Circuit Breaker may require an additional to 2 days to ship.

Shipping

Rigging Shoppe ships to Canada only. ALL prices listed on this website in Canadian dollars.

Shipping within 24 hours if possible. Delivery usually 2 - 5 business days in Canada.

Shipping charges will be visible before entering credit card information when ordering.

Learn about our complete shipping policy here.

Item# 7314

May be suitable for use when military specifications are required under CFR 46.

Specifications:
  • Amperage:25A
  • Actuator Style:Metal Toggle
  • Poles:2
  • Maximum Voltage:277V AC
  • 65V DC
  • Circuit Breaker Type: Magnetic Hydraulic—Trip free
  • Interrupt Capacity:1500A AC
  • 7500A DC
  • Minimum Operating Temperature:-40° C
  • Maximum Operating Temperature:85° C
  • Mounting Boss:1/2-32 Hex Nut SS
  • Mounting Nut Torque:30in-lb (3.39 Nm)
  • Mounting Screw:6-32 SS
  • Mounting Screw Torque:7 in-lb (0.79 Nm)
  • Screw Terminal Torque:14 in-lb (1.58 Nm)
  • Switching Cycles:6000 Electrical
  • 4000 Mechanical
  • Terminal Screws:10-32 SS
  • Weight:0.13lb (0.06 kg)
