Item# 6008200

Switches isolated battery banks to all loads or combines battery banks to all loads.

Features:

• Ignition protected—safe for installation aboard gasoline powered boats
• Case design allows surface or rear panel mounting

Specifications

• Switch Type: Selector 3 Position
• Color:Black
• Switch Positions:3
• Battery Combine:No
• Alternator Field Disconnect: No
• Maximum Voltage:32V DC
• Stud Size:3/8"
• Terminal Stud Torque:120 in-lb (13.56 Nm)
• Continuous Rating: 300A
• Intermittent Rating: 500A (5 Min)
• Cranking Rating: 30 sec 900A
• Battery Inputs:2
• Cable Clearance For 4/0 AWG Cables:1.12in (28.45 mm)
• Cable Size to Meet Ratings4/0 AWG: (120mm²)
• 4/0 AWG (130mm²)
• Mounting Holes:Accept 10 Screw
• Stud Material:Tinned Copper
• Stud Torque:120 in-lb (13.56 Nm)
• Terminal Stud Size:3/8" - 16 (M10)
