Item# 1839
The M2 Organic LED Digital Monitor measures essential electrical system parameters with adjustable alarms and an auto-dimming display.
The M2 Monitors include a MOSFET External Circuit Relay (ECR) which can be used to control external circuits based on any value measured by the M2.
Features:
- Auto-dimming, bright Organic LED display is easy to read
- 80dB alarm on all models
- Isolated 500mA MOSFET relay
- Intuitive tank level monitoring
- Monitor up to 4 tanks
- Auto calibration for unique tank shapes
- Compatible with common sending units
Specifications:
- Meter:Tank
- Function:Monitors tank volume in up to 4 tanks
- Resolution:1%
- Alarm/Relay Activation:High and Low Level
- Display Size:55mm x 28mm
- Input Voltage:7-70V DC
- Range:0.3W-1.0W
- Tank Alarms:80dB
- Tank Shapes:Custom shapes, auto calibration
- Weight:4.00lb (1.81 kg)
