Blue Seas Systems 3 Amp Terminal Circuit Breaker

Item# 2129

Features:

• Branch circuit breakers (can also be used for 24-hour circuit protection)
• Compact design enables high density circuit protection configurations
• Push-to-reset operation
• “Trip Free” design cannot be held “ON” during fault current condition
• Ignition protected - Safe for installation aboard gasoline powered boats

Specifications :

• Amperage:3A
• Maximum Voltage:32V DC
• Mounting:Panel Mount 3/8-27 UNS
• Circuit Breaker Type: Thermal trip, manual push-button reset only
• Terminal Type:8 Screw
• Interrupt Capacity: 3000A 14.7V
• 2500A 28V
• Minimum Operating Temperature:-10° C
• Maximum Operating Temperature:60° C
• Screw Terminal Torque:6 in-lb (0.68 Nm)
• Weight:0.09lb (0.04 kg)
