Self-contained sheaves are designed for sailors to use in custom applications.

Wire sheaves ride on high-load composite bearings. They are hardcoat-anodized aluminium with PTFE impregnation.

Specifications

• Sheave Ø (mm): 51 mm
• Sheave Ø (in): 2 in
• Width (mm): 10 mm
• Width (in): 13/32 in
• Weight (g): 43 g
• Weight (oz): 1.5 oz
• Center pin Ø (mm): 8.1 mm
• Center pin Ø (in): 5/16 in
• Maximum line Ø (mm): 6 mm
• Maximum line Ø (in): 1/4 in
• Maximum wire Ø (mm): 5 mm
• Maximum wire Ø (in): 3/16 in
• Maximum working load (kg): 907 kg
• Maximum working load (lb): 2000 lb
