Low-friction Bullet blocks lead control lines aft. They are compact and lightweight, with fast trim and release under high or low loads.
A range of styles lets these blocks adapt to almost all control line applications.
Specifications
- Sheave Ø (mm): 29 mm
- Sheave Ø (in): 1 1/8 in
- Length (mm): 95 mm
- Length (in): 3 3/4 in
- Weight (g): 50 g
- Weight (oz): 1.75 oz
- Maximum line Ø (mm): 8 mm
- Maximum line Ø (in): 5/16 in
- Fasteners (mm): 5 FH mm
- Fasteners (in): #10 FH in
- Mounting hole spacing (mm): 79 mm
- Mounting hole spacing (in): 3 1/8 in
- Cutout (mm): 21 x 67 mm
- Cutout (in): 13/16 x 2 5/8 in
- Maximum working load (kg): 181 kg
- Maximum working load (lb): 400 lb
- Breaking load (kg): 907 kg
- Breaking load (lb): 2000 lb
