Lofrans Project X-1 Windlass Capstan 500W 1/4"HT
The Lofrans Project X-1 Windlass Capstan 500W 1/4”HT combines performance and versatility with a choice of drum or low-profile design. It features independent gypsy and drum operation, a rope and chain combination gypsy, and a spring-loaded arm for smooth chain and rope management. A manual chain release and pre-installed chain counter magnet add precision and ease of use.
Built for durability, the windlass includes an IP67-rated motor cover and a marine-grade anodized aluminum gearbox. Standard equipment includes a dual-direction solenoid pack, gypsy for chain and rope, handle, and a QR code for easy access to the instruction manual.
| Construction | DARK Chromed Bronze |
| Motor Size | 500 |
| Chain size | 1/4" HT |
| Low profile or Drum | drum/capstan |
| Power Supply (V) | 12V |
| Maximum Pull (kg) | 630 |
| Working Load (kg) | 95 |
| Amps at Working Load (A) | 60 |
| Line Speed at Working Load (m/min) | 23 |
| Max Line Speed (m/min) | 26 |
| Net Weight Low Profile (kg) | |
| Net weight with Drum (kg) | 11 |
