The Lofrans Project X-1 Windlass Lo-Pro 500W 1/4”HT is a versatile and reliable anchoring solution with a choice of drum or low-profile design. It features independent gypsy and drum operation, a rope and chain combination gypsy, and smooth chain and rope management with a spring-loaded arm. A manual chain release and pre-installed chain counter magnet enhance precision and ease of use.
Built for durability, it includes an IP67 motor cover and a marine-grade anodized aluminum gearbox. Standard equipment includes a dual-direction solenoid pack, gypsy for chain and rope, handle, and a QR code for the instruction manual.
| Construction | DARK Chromed Bronze |
| Motor Size | 500 |
| Chain size | 1/4" HT |
| Low profile or Drum | lo-pro |
| Power Supply (V) | 12V |
| Maximum Pull (kg) | 630 |
| Working Load (kg) | 95 |
| Amps at Working Load (A) | 60 |
| Line Speed at Working Load (m/min) | 23 |
| Max Line Speed (m/min) | 26 |
| Net Weight Low Profile (kg) | 10 |
